QUICKLOOP RELEASE SYSTEM
QUICK RELEASE SYSTEM (QRS)
You should be familiar with the operation of the QRS
in the event of a situation where you wish to activate
the QRS feature.
QRS - OPERATION
Grab the release body and firmly push away from
your body (in the direction of the arrow) until it
meets the bottom of the spinning handle (FIG
1). Activating this primary quick release (QR1)
will still leave you attached to your kite via the 1X
Security line.
For complete separation from your kite, you will need
to activate Quick Release Handle on your bypass
leash. This is covered in detail in the Bypass Leash
Operation Page 18.
QRS - SETTING / RESETTING
• Lift the QR1 body up the spinning handle shaft
until it sits and latches on the side of the QR1
Hinge body. (FIG 2)
• Take the open end of the loop and insert it into
the upper receiver section of the harness Loop
Body, until it stops. (FIG 2)
• Release the QR1 Body from the Catch.
• Lower the QR1 body back down the shaft until it
rests flush with the Harness Loop Body. Do this
by straightening out and centering the QR Body
to disengage the catch on the side. (FIG 3)
• Your QR System is now ready for use.
OPERATION
FIG 1
FIG 3
FIG 2
