22
Fig. 1a
3. Using the appliance
• Place the cylinder inside the cabinet in the space provided.
• Use this appliance only on a rm level surface.
• Before use ensure that the drip cup/tray is in place.
• Make sure the gas cylinder is correctly tted to the appliance.
• Ensure the cylinder control valve is in the open position.
• To light the appliance using the automatic igniter, push in and turn the control knob in an
anti-clockwise direction until spring resistance is felt. Hold the knob in this position for
3 – 5 seconds to allow the gas to ow and then turn the knob fully anti-clockwise to the
HIGH position. This will cause the automatic lighter to light the burner. Should the burner
not ignite the rst time, push in and turn the control knob to the OFF position and wait 5
minutes, repeat the process until the burner ignites.
• Note! All burners are tted with an automatic igniter.
• Cross lighting: To light the burners using cross lighting, light the left burner as described
above.
• To light the remainder of the burners, simply turn their control knobs to the HIGH position
while ensuring that the lighting sequence is such that any burner to be lit up is directly
adjacent to a burner which is already burning.
• Manual ignition: To light the burners manually, rst remove the cast iron grill plate and the
de ector plate directly underneath it. Ignite a match or relighter and position it next to the
left hand burner. Turn on the gas supply to that burner only by pushing the control valve in
and turning it in an anti-clockwise direction. This will ignite the burner. Once the burner is
ignited, carefully replace the de ector plate and cast iron grill plate. You will now be able to
light the remainder of the burners as described in ‘Cross lighting’ above.
• Use the control knobs to adjust the individual burner ame intensity to the desired level by
turning the knob anti-clockwise to decrease the ame and clockwise to increase it (see g.3).
• After use, rst close the valve on the gas cylinder. When the ame is extinguished, close
the burner control valves on the appliance by pushing and turning the control knobs fully
clockwise.
Fig. 2
Fig. 3
GB
NOTE
• Do not twist or pinch the hose. Ensure that it is kept away from the BBQ body so as to
prevent deterioration/damage to the hose caused by heat.
• Fit one end of the low pressure hose onto the regulator nozzle, and the other end onto the
Patio BBQ nozzle by pushing the ends on as rmly as possible. Clamp into position using a
hose clamp at both ends of the hose.
• Ensure that the connections are made securely and do not allow gas to leak.
• Check for gas leaks before using the appliance.
For use with an approved hose and regulator connected to a re llable gas container not
exceeding 9 kg and complying with local regulation in force.
• Do not obstruct the ventilation openings of the cabinet.
• Do not modify the appliance. Modifying the appliance may be dangerous.
• Warning: Since this barbecue has no restriction in the emission of unburned gas, this
barbecue must be installed and/or used OUTDOORS or in an AMPLY VENTILATED AREA.
Ensure this BBQ is installed in an AMPLY VENTILATED AREA, the area must have at least
25% of the surface (sum of the walls surface) area open.
• Do not move the appliance during use.
• Any modi cation of the appliance may be dangerous
• Warning: An LP cylinder not connected for use, shall not be stored in the vicinity of this or
any other appliance.
Fig. 1b
