XAM600.1
1.Line Input RCA Jacks: These inputs are for signal cables
from the source.
2.High Level Input: If your head unit does not have RCA
outputs, use the speaker outputs for the audio source.
3.Remote Bass Control: Remote controls the subwoofer level.
4.Smart Turn On: Turn on by headunit remote or high level input
auto start.
5.Power & Protection Indicators: The bi-color LED glows
green when power is on and no problems are present.
If one of the protection circuits comes on, it will change
to red.
1.Input Level Control: Enables the matching of input levels to
the output levels from the source.
2.Variable Bass Boost: 0~12dB
3.Subsonic: This setting acts as a low frequency cut off for your
subwoofer. The subwoofer will not play frequencies below the
subsonic setting.
4.Low Pass Filter: Variable from 50Hz to 150Hz
5.Phase Switch: 0°or 180°
MIN MAX
1
2
15
3
24 3
45
2
