XAM400.2
1.Line Input RCA Jacks: These inputs are for signal cables
from the source.
2.High Level Input: If your head unit does not have RCA
outputs, use the speaker outputs for the audio source.
3.Smart Turn On: Turn on by headunit remote or high level input
auto start.
4.Power & Protection Indicators: The bi-color LED glows
green when power is on and no problems are present.
If one of the protection circuits comes on, it will change
to red.
1.Input Level Control: Enables the matching of input levels to
the output levels from the source.
2.Variable Bass Boost: 0~12dB
3.Low Pass Filter: Variable from 50Hz to 150Hz
4.Crossover Mode: Low pass, Full range or High pass
5.High Pass Filter: Variable from 50Hz to 150Hz
4 5
1 2 3
1
2
34
MIN MAX
LOW PASS
HI PASS FILTER
3
