Symbols
The following symbols are the most common symbols
that will appear on a map screen.
I (Current Position): Your vehicle is shown as this
symbol. It indicates the current position and heading
direction of your vehicle on the map.
The destination symbol will
appear on the map after a
route has been planned
marking your final
destination.
The waypoint symbol will
be displayed on the map
after a waypoint has been
added to your route.
The waypoint symbol will be numbered from one through
five depending on how many waypoints have been set.
The distance to destination
symbol indicates the
distance to your final
destination. It only appears
when time is not available
or when you are scrolling
on the map without a
route planned.
The distance and time to
destination symbol
indicates the distance and
the estimated time
remaining to your final
destination or arrival time,
depending on the option
selected. See Configure
Menu on page 2-49
for more information.
2-43
