1.4 Technical Specifications
1.4.1 Packaging
The Mod. A 1735 – A 1835 modules are housed in a 5 TE-wide, 6U-high mechanics. The
Mod. A 1735B – A 1835B modules are housed in a 10 TE-wide, 6U-high mechanics.
1.4.2 External connections
The location of all components of the front panel is shown in Fig. 2.1, p. 8. The function
and electro-mechanical specifications of the external connectors are listed in the
following subsections.
CH 0..11 (A 1735 – A 1835): Mechanical specifications:
HV coaxial connectors
Radiall SHVR317580-type
Electrical specifications: high voltage output
according to specifications given in Table
2.1, p.6.
CH 0..27 (A 1735B – A 1835B): Mechanical specifications:
Multipin connector Radiall 691803004-type,
52 pin male (to be mated with Radiall
691802002-type
5
[SCEM 09.41.34.700.2]);
see Fig. 2.2 for pin assignment.
Electrical specifications: high voltage output
according to specifications given in Table
2.1, p.6.
HV EN CONNECTOR Mechanical specifications:
00-type LEMO connector.
Electrical specifications: board ENABLE
input, if connected to ground, the channels
are enabled. Refer to §
3.2, p.13 for further
details.
5
Requires 52 pins Radiall 691804300 [SCEM 09.41.33.830.7] type, to be installed using the insertion/extraction tool
Radiall 282549024 [SCEM 34.95.17.125.3] type.
