Cal-Royal CRCODE-204 - Mounting Post Location; Mounting Post Installation; Install Mounting Post

6605 Flotilla St., Commerce, CA 90040
Tel (323) 888-6601 Fax (323) 888-6699
www.cal-royal.com
&KHFNLIPRXQWLQJSRVW¿[LQJEROWV
and screws are well secured.
&5
&5
mounting plate
7KUHDG¿[LQJEROWVRQPRXQWLQJSODWH
according to the model you have.
Mounting Post Location
1. Install mounting post to outside lock
through mounting plate.
2. Fix mounting plate with 2 of M4x14 screws
to outside lock.
Mounting Post Installation
5
