OCKET REFERENCE GUIDE — 34
Rake-Wall — No Base
Find each stud size in a Rake-Wall with a
peak of 3 Feet 6 Inches and a length of 6
Feet. Use 16 Inches as your spacing
(default):
KEYSTROKE DISPLAY
1. Enter Rise and Run:
o o 0.
3 f 6 i r
ALT 3 PIES 6 PULG
6 f R RECR 6 PIES 0 PULG
2. Find Stud Lengths:
∑ PDEC 16 PULG
∑ PD 1 2 PIES 8-11/16 PULG
∑ PD 2 1 PIES 11-5/16 PULG
∑ PD 3 1 PIES 2 PULG
∑ PD 4 0 PIES 4-11/16 PULG
∑ BASE 0 PIES 0 PULG
3. Find Rake-Wall Angle of Incline:
∑ INCL 30.26°
Note: To enter a base, enter the base height
prior to pressing the ∑ key (e.g., 5 f ∑).
