P
OCKET REFERENCE GUIDE — 36
(Cont’d)
KEYSTROKE DISPLAY
2. Recall stored 7-1/2 Inch desired Riser
Height and find stair values:
® s C-AL 7-1/2 PULG
s C-AL 7-9/16 PULG*
s CHUE 16.
s C+/– 0 PULG
s H-AN 9-15/16 PULG*
s HUE 15.
s H+/– 0-1/16 PULG
s LRGO 15 PIES 7-5/16 PULG
s INCL 37.27°
*A in the display means the calculated Riser
Height or Tread Width is greater than the stored
desired Riser Height or Tread Width.
