Channel
Arr
Specification Page
1 2 3 4 5 6 7 8 9
OCX x x x x x x x x option collector cooling collector 1 18
OCX1 x option collector cooling collector 1 18
CMX x* x* x* x* x* x* x* x* maximum temperature collector 1 18
CMX1 x* maximum temperature collector 1 18
OKN x x x x x x x x option minimum limitation collector 1 18
OKN1 x option minimum limitation collector 1 18
CMN x* x* x* x* x* x* x* x* minimun temperature collector 1 18
CMN1 x* minimun temperature collector 1 18
OCF x x x x x x x x option antifreeze collector 1 18
OCF1 x option antifreeze collector 1 18
CFR x* x* x* x* x* x* x* x* antifreeze temperature collector 1 18
CFR1 x* antifreeze temperature collector 1 18
EM2 x emergency temperature collector 2 18
OCX2 x option collector cooling collector 2 18
KMX2 x* maximum temperature collector 2 18
OCN2 x option miminum limitation collector 2 18
CMN2 x* minium temperature collector 2 18
OCF2 x option antifreeze collector 2 18
CFR2 x* antifreeze temperature collector 2 18
PRIO x x x priority 19
tST x x x stop time 19
tRUN x x x Ciruclation time 19
OREC x x x x x x x x x option reccoling 19
O TC x x x x x x x x x option tube collector 19
DT3O x x switch-on temperature difference 3 17
DT3F x x switch-off temperature difference 3 17
MX3O x x switch-on treshold for maximum temp. 17
MX3F x x switch-off treshold for maximum temp. 17
MN3O x x switch-on treshold for minimum temp. 17
MN3F x x switch-off treshold for minimum temp. 17
AH O x switch-on temp. for thermostat 1 20
AH F x switch-off temp. for thermostat 1 20
OHQM x x x x option WMZ 16
FMAX
maximum flow 16
MEDT
antifreeze type 16
MED% MEDT MEDT MEDT MEDT antifreeze content 16
t1 on x Switch on time 1 thermostat 20
t1 off x Switch off time 1 thermostat 20
t2 on x Switch on time 2 thermostat 20
t2 off x Switch off time 2 thermostat 20
t3 on x Switch on time 3 thermostat 20
t3 off x Switch off time 3 thermostat 20
HND1 x x x x x x x x x manual operation relay 1 20
HND2 x x x x x x x x x manual operation relay 2 20
LANG x x x x x x x x x Language 20
UNIT x x x x x x x x x Change over °FAH / °CEL 20
PROG XX.XX program number
VERS X.XX version number
