General: Radio:
Power Supply: 12VDC FM-RDS.
Max Power output 55Wx4 Frequency range 87.5-108.0 MHz
Suitable speaker impedance 4-8 Ohm Signal/noise ratio ≥40dB
Fuse 5A Noise limited sensitivity ≤37dBf
Dimensions (WxHxD) 178x50x40mm
USB/SD:
Transmission:
Frequency response 100Hz-18kHz
Bluetooth version 5.0 Signal/noise ratio >45dB
Bluetooth Frequency range 2402-2480 Mhz T.H.D. ≤5% (1KHz)
Max e.r.p. <100mW/20dBm Channel isolation(1KHZ):≥30dB
Signal to noise ratio (1KHZ) ≥45dB USB Charge Output 5.0VDC, Max 1.5A (7.5W)
Channel isolation (1KHZ) ≥30dB
Voltage harm. distortion (1KHZ) <5% DAB+
Frequency range 174-240 MHz
Antenna type (included) Screen mount / male SMA
connector / Active
(with +5VDC phantom power source)
Note: Specifications and the design are subject to change without notice due to improvements in technology.
We are continuously improving/updating our products and product information. It’s therefore possible that there is a difference
between the description in this manual to the operation of the product. If something different or not clear, always check our
website for the most current version.
INSTALLATION
