S320 OCS Repair and Diagnostics Field Guide
Page 7 of 22
1 INTRODUCTION
This field guide provides detailed information about the hardware components comprising the
CALIENT S320 Optical Circuit Switch (OCS).
Topics covered herein include safety precautions for installing, using and maintaining the switch;
an overview of OCS functionality and physical architecture, including precise descriptions of the
LEDs and physical interfaces located on the front and rear of the OCS chassis; and step-by-step
procedures for unpacking and installing a new S320 OCS.
This document also provides system specifications for regulatory, reliability, space, optical and
environmental requirements, as well as CALIENT part numbers for ordering additional systems
or hardware components that may eventually need replacement (e.g., fan filter).
