Technical data for the MES 400-(1-4) / Module A
Power: 400 VA (Watt), continuous operation
Mains input: Alternating voltage 230 V / 50 Hz, single phase
Range approx. 160 V – 265 V / 50 – 60 Hz.
230 Volt fusing: MES 400-1
MES 400-2
MES 400-3
MES 400-4
13 A circuit breaker
13 A circuit breaker and 16 A circuit
breaker for the airconditioning equip
ment
output
13 A circuit breaker and 30 mA differen-
tial circuit breaker
13 A circuit breaker and 30 mA differen-
tial circuit breaker, 16 A circuit breaker
for the airconditioning equipment output
230 volt outputs MES 400-1
MES 400-2/4
MES 400-3
7 outputs N / L1 / PE
7 outputs N / L1 / PE
+ 1 air-conditioning equipment output
7 outputs N / L1 / PE
12 Volt input: Direct current 12 V from the vehicle battery
Output: DC 12 V ; remaining ripple < 1%
12Volt outputs: 1 and 2
3 and 4
5 and 6
Circuit 1
Circuit 2
Circuit 3
15 A push-in fuse
15 A push-in fuse
10 A push-in fuse
Temperature: Ambient temperature of -25° C to +35° C. During op-
eration, the housing may heat up to approx. 80° C.
Cooling: By convection
Implementation: According to Association of German Electrotechnical
Engineers regulations and the provisions of the Instru-
ment Safety Act.
Design according
to:
EN 55081-1 / EN 55082-1 / EN 55022 /
EN 61 000-3-2 / EN 6100-4-4
Test labelling:
Housing: Aluminium, ventilated
Dimensions: Length = 295 mm / width = 340 mm / height = 100 mm
