CONTENTS
INTRODUCTION 3
CHECK LIST 3
APPROVALS 3
CONSTRUCTION 4
INSTALLATION 4
LOCATION 4
COLD WATER INLET 5
DIMENSIONS AND WEIGHTS 6
VENT / OVERFLOW 7
ELECTRICAL CONNECTIONS 8
USER INSTRUCTIONS 8
SCALE 9
GENERAL OPERATION 9
CLEANING 9
TROUBLE SHOOTING 10
ACCESSORIES 11
SPARE PARTS 12/13
EXPLODED DIAGRAM 14/15/16/17
SERVICE INSTRUCTIONS 18/19
GENERAL FUNCTION 20
WIRING DIAGRAM 21
SERVICE HISTORY NOTES 22
WARRANTY 23
PRODUCT SPECIFICATION 24
INTRODUCTION
Thank you for purchasing a boiler from the Calomax Eclipse range.
All our products are designed to give years of simple, reliable
operation. To ensure this, it is important that the installation and
subsequent servicing and maintenance is carried out by a suitably
qualifi ed engineer in accordance with these instructions. For
assistance in fi nding a suitable engineer in your area, visit our
website www.calomax.co.uk, contact our service department on
0113 249 6681 or e-mail: service@calomax.co.uk
CHECK LIST counter top models
Before commencing installation, check that the following parts have
been supplied with the boiler:
1. Wall mounting bracket
This product conforms to the CE marking directive 93/68/EEC
through compliance with the following standards:
Electromagnetic Compatibility Directive
Low Voltage Directive 73/23/EEC in accordance with:
BS EN 60335-2-75:2004. Compliance with these standards
has been confi rmed through testing by an independent NAMAS
approved body
APPROVALS
PAGE
CHECK LIST wall mounted models
Before commencing installation, check that the following parts have
been supplied with the boiler:
1. WRAS approved fl exible water inlet hose suitable for
potable water.
2. Drip tray kit
The tap handle and drip tray (part ref: MDTBK
where supplied) have been treated with Steritouch
additive and independently tested to prove
the effectiveness of the surface hygiene.
