Calphalon BVCLDCG1 - Product Diagram

5
PRODUCT DIAGRAM
1. Water Reservoir Lid
2. Water Reservoir
3. Water Window
4. Removable Cone Style Filter Basket*
5. Brew Basket
6. 10 Cup Glass Carafe*
7. LCD Screen Display
8. BREW LATER, STRONG, and BREW/OFF Button
9. HR/Warming timer and MIN Selector Buttons
10. Warming Plate
11. Cord Storage
*These parts can be replaced on Calphalon.com
or at 1-800-809-7267
1
2
3
4
6
11
10
8
7
9
5
