SECTION 12: (-F) OPTION ®
making
since 1986
ater work
1. Press the blue ARROW keys to
move the cursor to the K: setting.
2.
Press the PLUS or MINUS keys to
change the number.
3.
Press the blue ARROW keys to
move the cursor to the OFFSET:
setting.
4.
Press the PLUS or MINUS keys to
change the number.
Note:
The two settings that must be set are the K
value and the Offset. If you know these values enter
them now. If not, Call Calsense at 1-(800)-572-8608
for assistance.
The ranges for these two settings are:
• K:
0.200 to 800.00
• OFFSET:
0.000 to 1.000
12A.2 Regular flow meter setup
If the answer to Use your own K & Offset is NO.
1.
Press the blue ARROW keys to move
the cursor to the FLOW METER SIZE:
setting.
2.
Press the PLUS or MINUS keys to
change the flow meter type.
Refer to the chart (Figure 12.5), to choose the
correct flow meter type.
MODEL NUMBER SIZE
FM-1
FM-1B
FM-1.25B
FM-1.5
FM-1.5B
FM-2
FM-2B
FM-3
1” PLASTIC FLOW METER
1” BRASS FLOW METER
1 ¼” BRASS FLOW METER
1 ½” PLASTIC FLOW METER
1 ½” BRASS FLOW METER
2” PLASTIC FLOW METER
2” BRASS FLOW METER
3” PLASTIC FLOW METER
Figure 12.5
12B. Point of Connection 2 & 3 (POC 2 & 3)
POC 2 & 3 can be set up individually for use with
irrigation or for non-irrigation use. They can also
have individual settings for the Master Valves type,
and Flow Meter type and size used.
12B.1 POC Use with irrigation
When setting up Point of Connection 2 or 3 for use
with irrigation the programming steps are the same
as used for Point of Connection 1. Each point of
connection will be set up individually, and the IS
THIS POC USED WITH IRRIGATION? setting will
be set to YES (See figure 12.6).
Point of Connection: POC 2
Flow Meter in use ? YES
Use your own K & Offset? NO
Is this POC used with irrigation? YES
Flow Meter Size: FM-1.25B
POINT OF CONNECTION (MV & FM)
Master Valve is NORMALLY CLOSED
Figure 12.6
12.B.2 POC Use with Non-irrigation
When setting up Point of Connection 2 or 3 for use
with Non-irrigation the programming steps are a little
different. Each point of connection will be set up
individually, and the IS THIS POC USED WITH
IRRIGATION? Setting will be set to NO for any Point
of Connection that is not used with irrigation and
requires an individual schedule.
The POINT OF CONNECTION (MV & FM) screen is
displayed (Figure 12.7).
