Cama Handi-Lift ML7 - Table of Contents

Handi
-
Lift ML7
© 20
2
1
Page
2
Version
1.
2
Table of content
1 Introduction .............................................................................................. 3
1.1 Check the parts and drawing .................................................................. 3
1.2 Electrical installation ............................................................................. 3
Forces on the building ................................................................................ 4
Install the tower ........................................................................................ 4
3.1 Tower positioning ................................................................................. 4
Installing the lift unit .................................................................................. 7
4.1 Attach the back frame to the tower ......................................................... 7
4.2 Connect the electrical ........................................................................... 8
4.3 Connect the platform to the back frame ................................................... 9
4.4 Connect the power ............................................................................. 10
4.5 Load cell adjustment ........................................................................... 11
4.6 Handicap symbol ................................................................................ 12
Filling oil ................................................................................................ 12
Final touch ............................................................................................. 13
Install the gate ........................................................................................ 14
Installation test certificate ......................................................................... 17
Declaration A .......................................................................................... 18
