Fig. 9a Fig. 9b
4.3 Connect the platform to the back frame
Mount the platform to the back
frame using
the two screws and nuts
(M12x160/M12x180).
If necessary, adjust the lower position of
the platform using the set screws.
Fig.
10
Plug the remote lead into the control board. Press the re-set button in order to start
up the system.
Fig. 11
