Cambium Networks cnWave Series User Manual

Hardware Overview 10
Hardware Overview
.The 60 GHz cnWave solution includes four types of wireless nodes:
l V1000 Client Node (CN)
l V2000 Client Node (CN)
l V3000 Client Node (available in two antenna sizes - 40.5 dBi or 44.5 dBi)
l V5000 Distribution Node (DN)
V1000
A Client Node (CN) that contains a wide-range, 80 degrees beamforming for easy installation. This CN is
powered by 802.3af PoE and supports up to 2 Gbps for PTP and PMP configurations.
Figure 2: V1000 CN
V1000 Wall and pole mount
The V1000 CN is supplied with a mounting plate and band clamp. The mounting plate can be used for
mounting the V1000 on a wall, or it can be used with the supplied band clamp to mount the V1000 on a
pole with a diameter in the range of 25 mm to 70 mm (1 inch to 2.75 inches). Note that the larger
diameters can be accommodated with the customer supplied clamps.
