Cambridge Audio 340A - Page 9

AP15185/3
AP PART
No.
DRAWING No DESCRIPTION QTY DESIGNATOR COMMENTS
47R Resistor 0.25W 1% metal film 1 R2
220R Resistor 0.25W 1% metal film 2 R3, R4
100K Resistor 0.25W 1% metal film 1 R1
100nF Ceramic NP0 or C0G 10% 4 C1, C4-C6
47uF 16V Radial Electrol
y
tic 1 C3
PY634 PIC16F72-I/SP 1 U1 Pro
g
rammed with AP14904/X
Version label for PIC 1 U1
Print with latest software version
number and stick on PIC.
PY260 BA6218 MOTOR DRIVE IC
1U2
As used in 540A. 4162-180002-300
SIL-8
p
acka
g
e
PD092 TSOP18 IR RECEIVER MODULE (VISHAY) 1 U3 As used in 540A 3001-183600-001
PY064 FLAT TOP BLUE LEDS (AS PER CURRENT
CAMBRIDGE
)
6 D1-D6
Please use flat top LED at standard
Azur hei
g
ht
ICP Pico
p
lex PF-50 6-wa
y
male header 1 CN1 Vertical
H8 2.54mm 90 1 CN2 Ri
g
ht-an
g
le connector 8-wa
y
H2 2.54mm 90 1 CN5 Ri
g
ht-an
g
le connector 2-wa
y
H3 2.54mm 90 1 CN3 Ri
g
ht-an
g
le connector 3-wa
y
AP14897/1 Azur 340A IR PCB cable 1
2400-020200-000 Tactile Switch 6 SW1, 2, 3, 4, 5, 6
As used on 540A, CD, Tuner, AV,
Phono/Aux, Ta
p
e/Mon, DVD
Ceramic Resonator F=4MHz 1 CRS1
10mm lon
g
W
ire link 11 LK1-11
AP14519/1 Blank PCB 1
Note:
AP14518/1-B is the IR PCB assembl
y
Cambridge Azur 340A Front Panel PCB BOM
AP14518/1-A is the switch and micro controller PCB assembly
9
