Cambridge Audio CXN v2 User Manual

25
7. Within Speaker Properties, navigate to the Advanced tab. Select the desired bit depth and sample rate preference. Once selected, select
Apply, then OK.
8. Your PC’s output will now playback via the CXN (V2).
Mac Setup
1. Connect your CXN (V2) to your Mac.
Using a USB audio cable (Type A to Type B), connect the USB Audio In on your CXN (V2) to a USB port on the Mac.
Note: If using a Mac without a USB Type A port, you may also use USB Type C (Thunderbolt 3) to USB Type B connection.

Cambridge Audio CXN v2 Specifications

General

Type	Network Streamer
DAC	Dual Wolfson WM8740
Digital Audio Outputs	S/PDIF Coaxial, TOSLINK Optical
Ethernet	Yes
Standby Power Consumption	<0.5W
Digital Filter	2nd Generation ATF2 up-sampling to 24-bit/384kHz
Supported Formats	ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
Connectivity	Ethernet, Wi-Fi
Bluetooth	Optional (via BT100 dongle)
Inputs	USB, Optical, Coaxial
Outputs	Balanced XLR, RCA
Analogue Audio Outputs	Balanced XLR, RCA
Compatibility	UPnP
Streaming Services	Spotify Connect, TIDAL, Qobuz, Internet Radio
Wi-Fi	Yes
Control	Remote Control
Dimensions	85 x 430 x 305 mm (H x W x D)
Sample Rates	up to 24-bit/192kHz
