Cambridge Audio CXN v2 User Manual

26
2. Select the USB Audio source.
If using the front panel controls of your CXN (V2), navigate to Home > Inputs > USB Audio.
If using the StreamMagic app, go to the Home tab, then select USB Audio within the Sources section.
3. Switch the USB Class.
If using the front panel controls of your CXN (V2), navigate to Home > Settings > Audio > USB Audio Class > Then toggle between USB
Audio Class 1.0 or 2.0.
If using the StreamMagic app, go to the Home tab, locate the CXN (V2) Settings > USB Audio Class > Then toggle between USB Audio
Class 1.0 or 2.0.
4. Within the System Preferences of the Mac, locate the Sound settings. Select the CA CXN Audio Class 1 / 2 as the output sound device.
5. On the Mac navigate to Applications > Utilities > Audio MIDI Setup. Select the CA CXN Audio Class 1 / 2 as the output sound device on
the left column, and then using the drop-down options select the desired bit depth and sample rate preference.

Cambridge Audio CXN v2 Specifications

General

Type	Network Streamer
DAC	Dual Wolfson WM8740
Digital Audio Outputs	S/PDIF Coaxial, TOSLINK Optical
Ethernet	Yes
Standby Power Consumption	<0.5W
Digital Filter	2nd Generation ATF2 up-sampling to 24-bit/384kHz
Supported Formats	ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
Connectivity	Ethernet, Wi-Fi
Bluetooth	Optional (via BT100 dongle)
Inputs	USB, Optical, Coaxial
Outputs	Balanced XLR, RCA
Analogue Audio Outputs	Balanced XLR, RCA
Compatibility	UPnP
Streaming Services	Spotify Connect, TIDAL, Qobuz, Internet Radio
Wi-Fi	Yes
Control	Remote Control
Dimensions	85 x 430 x 305 mm (H x W x D)
Sample Rates	up to 24-bit/192kHz
