Pag. 10 - - 02/2021 - © CAME S.p.A.
Description
Wireless gateway device or Bluetooth selector for controlling Came operators compatible with
the CRP protocol.
The device offers Wi-Fi connectivity with any household router. You can control an operator from
an Android or iOS smartphone via the CAME Automation app.
Where you do not have access to a Wi-Fi connection, you can set the device to Bluetooth mode
and use it as a selector (5 users). The CAME Automation BT app is available for Android and iOS.
To switch between modes, use the change mode button. The LEDs indicate the mode type.
Description of parts 🅰
❶ CAME WIRELESS GATEWAY
❷ POWER LED (red)
❸ Bluetooth LED (blue)
❹ Wi-Fi LED (green)
❺ Operator connector
❻ RSE adapter cable
❼ CAME WIRELESS GATEWAY connector
❽ RSE card connector
❾ String
❿ String hole
⓫ Code label
⓬ Change mode button
Size 🅱
Installation 🅲
Type of connections
🅐 To a control board with a specific connector;
🅑 To a control board with an RSE connector.
Connection
⚠
For the system to work properly, before inserting the device in the control board connector,
you MUST CUT OFF THE POWER MAINS and remove any emergency batteries.
After you have connected the device, switch the power back on.
⚠
Check that the red LED on the device is flashing. This indicates that the device is working
properly and is ready to be configured.
