NUMBERING OF CALL KEYS
Organisation of call codes where there are call keys
In manual programming the call keys are arranged as in the
diagram for a maximum of 98 keys.
In this way, for example, pressing key 6 corresponds to en-
tering number 6 on the MTMKB keypad followed by key .
Technical data
Type MTMKB
Power supply (V DC)
10.7 to 18
MAX consumption (mA) 55
MIN consumption (mA) 5
Storage temperature (°C) -25 to +70
Operating temperature (°C) -25 to +55
Protection rating (IP) 54
General precautions
IMPORTANT! Important safety instructions: READ CAREFULLY!
• Installation, programming, commissioning and maintenance must only be carried out by expert qualifi ed tech-
nicians in full compliance with the regulations in force.
• Wear anti-static shoes and clothing if working on the electronic circuit board.
• Keep this precaution information.
• Disconnect the power supply during any cleaning or maintenance work.
• The product must only be used for the purpose for which it was expressly designed. Any other use is to be
considered dangerous.
• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.
• This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1 - This device may not cause harmful interference.
2
- This device must accept any interference received, including interference that may cause undesired operation.
DESCRIPTION
Keypad module connectible on BUS.
Assembly and removal of the module must take place with no power to the entry panel.
❶ Sockets for the connector to connect additional modules.
