FA01702M4A - 06/2022FA01702M4A - 06/2022
Technical data
Type RIOLX8WS
Power supply (V DC) 3
Stand-by absorption (μA) 80
Current draw in transmission (mA) 15
two, lithium CR123A (mAh) batteries 1700
Battery life (months)* 24
Radio frequency (MHz) 868.95
Radio range over clear areas (m)** 30 max.
Storage temperature (°C)*** -25 ÷ +70
Average product life (cycles)**** 100,000
Transmission power (dBm) 10 max.
Materials PC-ABS
(*)The battery duration is calculated on a yearly average of 20 daily-
maneuvers.
(**)Do not place the RIOCN8WS or the RIOCT8WS card behind walls,
metal fences or any other obstructions that could interfere with radio
communications.
(***) Before installing the product, keep it at room temperature where
it has previously been stored or transported at a very high or very low
temperature.
(****) The average product life is a purely indicative estimate. It applies
to compliant usage, installation and maintenance conditions. It is
also infl uenced by other factors, such as climatic and environmental
conditions.
Installing
⚠Fit the RIOLX8WS photocells near the RIOCN8WS or the RIOCT8WS
card, so as not to have any metal or cement obstructions.
- Fasten the base ⑦onto the chosen surface. When fi tting the device
to a wall, you will need to use THE KIAROS BRACE (not supplied).
- Fit the card into the base and fasten using the supplied screws
.
NB: Do not change the antenna's position.
- Save, the RIOLX8WS transmitter and receivers , ON the RIOCT8WS or
the RIOCN8WS CONTROL CARD (SEE THE SAVING CHAPTER).
- Make the necessary functional checks (see the manual FOR the
RIOCT8WS OR THE RIOCN8WS).
- Finish assembling the RIOLX8WS fl ashing light.
Saving
Fit the batteries into all accessories that will be saved.
After three minutes, the devices shift into stand-by mode; to
reactivate them, press T1 or T2 for one second.
Check that the CH1 and CH2 LEDs are fl ashing red simultaneously,
otherwise do a reset (see THE RESETTING PROCEDURE).
Saving T1
Press, for one second, the T1 button on the RIOLX8WS card: the CH1
and CH2 LEDs will fl ash red in alternation. Press, for one second,
the PROG button on the RIOCN8WS card or the RIOCT8WS card: the
WIRELESS LEDs, on the RIOCN8WS or the RIOCT8WS card, will switch
from fl ashing to o , and the CH1 LED on the RIOLX8WS card will fl ash
blue once and then switch o .
