CamFive CFL-CMA1610T - Air Assist Compressor Connection

16
3. Connect the air assist compressor to the air pump inlet in the laser cabinet.
4. Set the laser tube in place. The picture below shows the laser tube in position and the
laser beam path. The end with the green/yellow wire (cathode) faces the first mirror.
