Adjusting Rotavator Width
Therotavatorwidthcanbeadjustedusingthefollowingcongurations:
Current unit No of
Tines
No of
Flanges
Increase or
Decrease
New
conguration
No of
Tines
No of
Flanges
52cm (20”) 16 4 Increase 66cm (26”) 20 6
66cm (26”) 20 6 Decrease 52cm (20”) 16 4
80cm (32”) 24 6 Decrease 66cm (26”) 20 6
PLEASENOTE:The46cmrotavatorattachment(12tineson4anges)cannotbeadjustedinsize
52cm (20”)-16tineson4anges
80cm (32”)-24tineson6anges
66cm (26”)-20tineson6anges
