Page 10 PSR/AM/0914
Replacing the Tines
To replace the tines, it is
necessary to remove the
rotavator attachment from
the power unit.
Once removed, turn the
rotavator upside down to
facilitate replacement of
the tines.
LOOK CAREFULLY AT THE
ORIENTATION OF THE
TINES.
Replace the tines one at a
time so that you can use
the remaining tines as a
reference.
IMPORTANT: When replacing the tines, enure that they are
mounted with the cutting edge in the same position as shown
in the picture above.
