Camtraptions PIR Motion Sensor v3 Manual Page 7
Operating!Mode!
The jumper marked A can be used to switch between stills and video mode.
Jumper A: Off: Stills mode (see Stills Manual)
On: Video mode (see Video Manual)
Wireless!Channel!
The jumpers marked B, C, D set the wireless channel. The jumper
configurations for each channel are shown below:
Setting
B
C
D
Channel 1
Off
Off
Off
Channel 2
On
Off
Off
Channel 3
Off
On
Off
Channel 4
Off
Off
On
Channel 5
On
On
Off
Channel 6
Off
On
On
Channel 7
On
On
On
Tx Disabled
On
Off
On
The corresponding channels on Camtraptions Wireless Receiver are as
follows:
Setting
1
2
3
4
Channel 1
On
Off
Off
Off
Channel 2
Off
On
Off
Off
Channel 3
Off
Off
On
Off
Channel 4
Off
Off
Off
On
Channel 5
On
On
Off
Off
Channel 6
Off
Off
On
On
Channel 7
On
On
On
On
Legacy!Mode!
This mode replicates the programs of the PIR v2. It is set as follows:
A: Off
B: On
C: Off
D: On
For instructions on how to use Legacy Mode, refer to the PIR v2 Manual.
!
!
