Quantity Range Frequency Range Accuracy
Current 1-20 x Ip 50 Hz +2%
Measurement Accuracy
Rated Data Rated current Ip :1A or 5A
Rated frequency Fn : 50 Hz
Drop out to Pickup Ratio >96%
DC Current Carrying Capacity 8A@30VDC / 0.3A@110VDC/ 0.2A@220VDC
Power consumption At Ip=1A 0.2 VA
in current circuit At Ip=5A 0.4 VA
Thermal withstand Dynamic current withstand
capacity in for 1 Sec : 100 x Ip
current circuit for 10 Sec : 30 x Ip
continuously : 4 x Ip
Protection-Front Panel IP-54
Weight Approx. 700 gms
Measuring Input
Trip Contact Rating
Mechanical Life Min. 10,000,000 operations
(at 36,000 operation/Hr.)
Di-electric Strength (Initial)
between Contacts of the same polarity 1000 VAC, 50/60Hz for 1 minute
between Contacts & Coil 4000 VAC, 50/60Hz for 1 minute
Surge withstand capacity
between Contacts & Coil 10,000 V (1.2 x 50 us)
Contact current rating (trip) 8A
Switching voltage 250VAC
Output contact type Ag Alloy + gold plating (Cd free)
12
