Common Setting
Parameter Display Setting Range Step Default
Min. Max. Size Setting
Phase CT ratio P-CTR 1 9999 1 1
Reset Delay R_dly 0 20 Sec 0.1 Sec 0 Sec
Fault popup FltPop Enable Disable 1 Enable
(These are the settings common for all protections)
Auxiliary voltage range 18-300V DC / 60-280V AC
Power consumption Quiescent approx. 3W , Operating <7W
Auxiliary Supply
Parameter Range Step size Tolerances
Id> 5 - 90% x In 1% +3% of set value
td 0.02 - 150sec 0.01 sec + 20msec
Differential Current
Parameter Display DO Assign
Current differential Id> DO1 / DO2 / DO3
Self supervision SlfSup DO1 / DO2 / DO3
DO Assignment
Protocol CSE proprietary : available with PC software
Cable required for interface USB cable type (A to A)
Front (USB) Communication
11
