Candy CCE116/1X User Manual

38
INSTALLATION (VENT INSIDE)
If you do not have an outlet to the outside, exhaust pipe is not required and
the installation is similar to the one show in section “INSTALLATION (VENT
OUTSIDE)”.
Activated carbon filter can be used to trap odors.
In order to install the activated carbon filter, the grease filter should be
detached first. Press the lock and pull it downward.
Plug the activated carbon filter into the unit and turn it in clockwise direction.
Repeat the same on the other side.
NOTE:
o Make sure the filter is securely locked. Otherwise, it would loosen and
cause dangerous.
o When activated carbon filter attached, the suction power will be
lowere
40

Candy CCE116/1X Specifications

General

Bulb type	LED
Bulb power	2 W
Number of bulbs	2 bulb(s)
Noise level	62 dB
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	56 dB
Maximum extraction power	305 m³/h
Lighting efficiency class	A
Fluid dynamic efficiency class	E
Grease filtering efficiency class	C
Motor power	- W
Connected load	1000 W
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	36 kWh
Type	Wall-mounted
Cord length	1.5 m
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	2 pc(s)
Grease filter type	-
Package depth	245 mm
Package width	650 mm
Package height	540 mm
Package weight	8850 g

Weight and Dimensions

Depth	480 mm
Width	600 mm
Height	- mm
Weight	7300 g
Height (max)	940 mm
Height (min)	573 mm
Height without chimney	180 mm
