Candy CCE116/1X User Manual

34
INSTALLATION （ wall mounting ）
If you have an outlet to the outside, your cooker hood can be connected as
below picture by means of an extraction duct (enamel, aluminum, flexible pipe or
inflammable material with an interior diameter of 150mm)
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hood should be placed at a distance of 65~75cm above
the cooking plane for best effect.
3. Drill 3 x 8mm holes to accommodate the bracket. Screw and tighten
the bracket onto the wall with the screws provided.
Wall plug
Wall bracket
107.5mm
Screw(4mm x 30mm)
35

Candy CCE116/1X Specifications

General

Bulb type	LED
Bulb power	2 W
Number of bulbs	2 bulb(s)
Noise level	62 dB
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	56 dB
Maximum extraction power	305 m³/h
Lighting efficiency class	A
Fluid dynamic efficiency class	E
Grease filtering efficiency class	C
Motor power	- W
Connected load	1000 W
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	36 kWh
Type	Wall-mounted
Cord length	1.5 m
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	2 pc(s)
Grease filter type	-
Package depth	245 mm
Package width	650 mm
Package height	540 mm
Package weight	8850 g

Weight and Dimensions

Depth	480 mm
Width	600 mm
Height	- mm
Weight	7300 g
Height (max)	940 mm
Height (min)	573 mm
Height without chimney	180 mm
