Candy CCE116/1X User Manual

41
MAINTENANCE
Before cleaning switch the unit off and pull out the plug.
I. Regular Cleaning
Use a soft cloth moistened with hand-warm mildly soapy water or
household cleaning detergent. Never use metal pads, chemical, abrasive
material or stiff brush to clean the unit.
II. Monthly Cleaning for Grease Filter
ESSENTIAL: Clean the filter every month can prevent any risk of fire.
The filter collects grease, smoke and dust…... so the filter is directly
affecting the efficiency of the cooker hood. If not cleaned, the grease
residue (potential flammable) will saturate on the filter. Clean it with
household cleaning detergent.
III. Annual Cleaning for Activated Carbon Filter
Apply SOLELY to unit that installed as a recirculation unit (not vented to
the outside). This filter traps odors and must be replaced at least once a
year
depending on how frequent the cooker hood used.
IV. Changing a light bulb
Remove the screws on the glass, take off the hood glass. Find the
bulb that requires replacement, you will find it located in the light
fixture which is inside the exposed section of the canopy.
Disconnect the light wiring point and remove the bulb holders and
wiring from the hood. Important: It’s not possible to replace the bulbs
individually, it will be necessary to obtain the bulbs, bulb holders and
wiring as a complete part. (LED light: MAX 1.5W)
Fit the replacement bulbs, bulb holders and wiring in the same
manners as the originals. Then reconnect the light wiring point.
43

Candy CCE116/1X Specifications

General

Bulb type	LED
Bulb power	2 W
Number of bulbs	2 bulb(s)
Noise level	62 dB
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	56 dB
Maximum extraction power	305 m³/h
Lighting efficiency class	A
Fluid dynamic efficiency class	E
Grease filtering efficiency class	C
Motor power	- W
Connected load	1000 W
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	36 kWh
Type	Wall-mounted
Cord length	1.5 m
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	2 pc(s)
Grease filter type	-
Package depth	245 mm
Package width	650 mm
Package height	540 mm
Package weight	8850 g

Weight and Dimensions

Depth	480 mm
Width	600 mm
Height	- mm
Weight	7300 g
Height (max)	940 mm
Height (min)	573 mm
Height without chimney	180 mm
