Candy CCE116/1X User Manual

40
On/Off button
It’s used for turning on/off the fan.
Speed plus button
For increasing the speed of the fan
Speed decrease button
For decreasing the speed of the fan.
Light button
Digital display
Fan speed display:"1" for Low speed, "2" for Medium speed,
"3" for High speed, “4” for Booster function.
Quick timer: Press & hold for 1 second, Digital display will
flashing & into 5 minutes count down, after 5 minutes motor & light
will turn off automatic & Buzzer sound for 1 second.
Booster function
This hood has a booster function. To activate the booster, Press
to speed 4, enter into highest speed while the hood is in use
and it will increase speed for 5 minutes, before slowing down
again.
42

Candy CCE116/1X Specifications

General

Bulb type	LED
Bulb power	2 W
Number of bulbs	2 bulb(s)
Noise level	62 dB
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	56 dB
Maximum extraction power	305 m³/h
Lighting efficiency class	A
Fluid dynamic efficiency class	E
Grease filtering efficiency class	C
Motor power	- W
Connected load	1000 W
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	36 kWh
Type	Wall-mounted
Cord length	1.5 m
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	2 pc(s)
Grease filter type	-
Package depth	245 mm
Package width	650 mm
Package height	540 mm
Package weight	8850 g

Weight and Dimensions

Depth	480 mm
Width	600 mm
Height	- mm
Weight	7300 g
Height (max)	940 mm
Height (min)	573 mm
Height without chimney	180 mm
