99
INSTALLATION
1
490
510
270
288
30
+ 0
– 2
+ 0
– 2
50
TECHNICAL INFORMATION FOR THE INSTALLER
Some models only: Before installing the cooktop, remove the protective lm.
These cooking hobs are designed to be embedded into kitchen xtures measuring 600 mm
in depth and from 30 to 40 mm thick.
In order to install the cooker top into
the kitchen xture, a hole with the
dimensions shown in g. 1.1 has to
be made, keeping in consideration the
following:
• within the xture, between the
bottom side of the cooker top and
the upper surface of any other
appliance or internal shelf there
must be a clearance of at least 30
mm;
• the cooker top must be kept no less
than 50 mm away from any side
wall (g. 1.2);
• the cooker top must be kept at a
distance of no less than 50 mm
from the rear wall (g. 1.1);
• there must be a distance of at least
650 mm between the hob and any
wall cupboard or extractor hood
positioned immediately above (see
g. 1.2);
• the coatings of the walls of the unit
or appliances near the cooktop
must be heat resistant.
Do not instal the appliance near
inammable materials (eg. curtains).
Fig. 1.1
Fig. 1.2
650 mm
50 mm
450 mm
