Note: If the above description can't be troubleshooting,
do not disassemble the repair yourself. Repairs carried out
by inexperienced persons may cause injury or serious
malfunctioning. Contact the local store where your
purchase was made. This product should be serviced by an
authorized engineer and only genuine spare parts should
be used.
When the appliance is not in use for long periods,
disconnect from the electricity supply, empty all foods and
clean the appliance, leaving the door ajar to prevent
unpleasant smells.
Reversing the door
1. Make sure that your refrigerator is unplugged.
2. Pry the hinge cover up and off, remove the three
screws that secure the upper hinge to the door, then
remove the hinge.
3. Remove the freezer compartment door from the
cabinet.
4. Remove the two screws that secure the center hinge.
5. Remove the refrigerator compartment door.
6. Remove the four screws that secure the lower hinge
to the right side of the cabinet, then remove the
hinge.
7. Remove the washer and nut that secure the pin shaft
to the right hole on the lower hinge, then remove the
shaft and pin screw
8. Insert the pin screw into the right hole and insert the
pin shaft into the left hole on the lower hinge,, then
secure the shaft with the washer and nut.
9. Install the lower hinge on the left side of the cabinet.
10. Remove the screw that secures the door stops from
the bottom right of the refrigerator compartment door,
then remove the door stops and install to the bottom left
side.
