TROUBLESHOOTING
Other Possible Faults
No gas to burner. •Thegasvalveshouldopenatthesametimeastheignitersparks.
If there is no gas to the burner when this occurs check the
solenoid coils for continuity.
•Checkthatthegaspressureispresentatthetestpointwhenthe
spark is being generated.
•Checkthatthereisgastotheinletofthegascontrol.
Fuse blowing. •Ifthefusecontinuestoblowcheckthesolenoidcoilsforasignsof
them being shorted.
•Checkthefanandwiringforshortcircuit.
Fault Codes Continued
Long Short Morse Code Meaning Action
3 1 ———•
Room fan (circulation
fan) pressure signal has
been interrupted.
Check the fan for dust build up and lint. Check that the
room air fan is spinning. Check that the pressure tubes are
connected correctly and not pinched or kinked. The black
tube should run from the black side of the pressure switch
to the bottom tapping on the fan venturi. The clear tube
should go from the light side of the pressure switch and to
the top tapping on the venturi. Make sure that the pressure
switch wires are connected correctly. One wire should be
to C (Common) and the other should be to NO (Normally
Open). If it still doesn’t work after checking the above,
change the pressure switch.
2 8 ——••••••••
Room fan (circulation
fan) pressure switch
has not switched within
hte expected time.
Check the fan for dust build up and lint. Check that the
room air fan is spinning. Check that the pressure tubes are
connected correctly and not pinched or kinked. The black
tube should run from the black side of the pressure switch
to the bottom tapping on the fan venturi. The clear tube
should go from the light side of the pressure switch and to
the top tapping on the venturi. Make sure that the pressure
switch wires are connected correctly. One wire should be
to C (Common) and the other should be to NO (Normally
Open). If it still doesn’t work after checking the above,
change the pressure switch..
