Cannondale Jekyll - SHOCK LINK; Component Identification

8
SHOCK LINK
M6X30
M6X30
M5X16
M5X16
M5X16
M5X16
KP169/
6
7
1
2
3
4
4
6
10
9
9
8
8
8
a
a
a
a
2
c
d
c
d
b
6
b
6
8.0 Nm, 71.0 InLbs Loctite 242 (blue)
5.0 Nm, 44.0 InLbs Loctite 242 (blue)
8
= 5.0 Nm, 44.0 InLbs - Loctite™ 242 (blue)
8
= 8.0 Nm, 71.0 InLbs - Loctite™ 242 (blue)
9
5
Identication
1. Shock Link 8. Pinch bolts
2. SS Lever Axle 9. Shock Mounting Bolt
3. DT Link Axle 10. Rear Brake Line
4. Main Shim a. gap
5. Link Tool (inc. KP169/) b. bearing inner race
6. Bearing (61802-2RS, 15X24X5) c. large end
7. Seat Stay d. small end
