7
1
9
11
6
8
10
2
4
3
12
NLG1-2
NLG1-2
(O.D. only)
Pin
2.5 Nm, Loctite 242 (blue)
5 Nm, Loctite 262 (red)
SFHS M3X6
SFHS M6X8
CABLE STOP
BUSHING
TOP NUT
LEVER MAIN
SPRING
CLAMP BRACKET
LEVER
RELEASE
SHCS M3X10
Pin
a
l
ig
n
Slot
BASE PLATE
c
a
ble to shoc
k
LEFT HANDLEBAR RIGHT HANDLEBAR
8. Install the Dyad RT2 back into the bicycle frame.
Clean the mounting bolt threads, apply Loctite 242 (blue)
and tighten to 8.0 Nm, 71 InLbs.
9. Secure the housing to the DT frame guide.
10. Test the lever for normal operation between the 150mm
and 90mm travel modes.
