4
1
3
8m
m
Allen key
B
A
4
2
3
1
2
3
BA
19 mm
12 N•m
(106 In•Lbs)
242
GREASE
GREASE
Cannondale Kit # KF100/
includes (1), 2X (3), and (4)
Cannondale Kit # KB61902/
includes 1X(2)
2
FRAME BORE
CAUTION
• Remove the rear wheel before servicing the pivot assembly. Support the swingarm
from dropping or falling to prevent damage to the seat tube.
• Remove chainstay bridge if applicable. See next page.
• Clean the pivot axle and frame bore. Apply a light film of bicycle bearing grease to
both grease before reassembly. Too much grease will collect damaging grit.
1. Pivot Axle
2. Bearings
3. Spacers
4. Pivot Nut
A - Rounded side of spacer faces frame
B - Flat side of spacers fits into bearing
To Next Page
