Cannondale PROPHET - SPECIFICATIONS

120017.PDF
25
specifications
ITEM PROPHET PROPHET MX
Frame Material 6061-T6, Tig Welded,, Aluminum Alloy
Maximum Tire Width 2.35”
Head Tube Headshok, Onepointfive
MAXIMUM FORK LENGTH 530mm 570mm
Seat Post Diameter 27.2 ±0.1 mm
Rear Shock Bushing Width
(Frame Mount)
27.4 ±0.1 mm
Rear Shock Bushing Width (Swingarm) 37.4 ±0.1 mm
Bolt Diameter 8.1 ±0.5 Mm
Rear Shock Eyelet-to-eyelet Length 200mm
Rear Wheel Travel 140
Rear Shock Stroke Length 50mm
Rear Shock Leverage Ratio 3:1 Regressive
Front Derailleur
31.8mm Bottom Pull, Traditional Swing
Bottom Bracket Shell
(Width, Thread Type)
68mm, English, E-Type
Chain Line 47.5 Mm
Dropout Spacing 135 Mm
Rear Hub Spacing 135 mm
Rear Axle Quick Release 12mm Thru Axle
Rear Brake Mount International Standard, 8” or 6”
Recommended Sag % of shock travel
XC 25 - 30
FR 30 - 40
