Cannondale TRIGGER - REPLACEMENT PARTS; Jekyll;Trigger Parts

21
134910 Rev 1.
Q
Q
B
C
C
O
Q
A
M4
Loctite 242 (blue)
6 Nm
A
I
34.9 mm
A
F
Loctite 242 (blue)
12 Nm
M5
Loctite 242 (blue)
12 Nm
M4
Loctite 242 (blue)
6 Nm
M2.5
Loctite 242 (blue)
2 Nm
N
F
G
K
E
A
B
M
L
D
CS-L
CS-R
DT & SS
H
P
P
J
A
1.5 N-m
M2.5
1 N-m
M2.5
1 N-m
M2.5
1 N-m
ENGLISHTRIGGER/JEKYLL - OWNERS MANUAL SUPPLEMENT
ID CODE DESCRIPTION
L
CK9017U00OS
17x30 Bearing Tool
KP197/SRM
Kit Bearing BB-Presst 30 SRM
M
KP388/
Seatbinder MTN 34.9
ID CODE DESCRIPTION
N
K32027
Internal Di2 Battery Mount
0 CK3117U00SM Trigger Crb DT Protector SM
CK3117U00MD Trigger Crb DT Protector MD
CK3117U00LG Trigger Crb DT Protector LG
CK3117U00XL Trigger Crb DT Protector XL
P
CK3187U00OS
Jekyll/Trigger Grommets
M
KP436/
Cable Guides Scalpel Si
For rear shock parts and service:
www.foxracingshocks.com
