Names of Parts

16

Handle Unit

Microphone Holder

(A 29)

213

4

1 Cable clamp

2 Locking knob

3 Accessory shoe

4 Sockets for the microphone holder (A 30)

(A 30)

1

4

3

2

1 Microphone lock screw

2 Microphone holder

3 Screw hole for the shoe mount bracket

4 Microphone cable clamp
