Canon EOS C70 - Page 201

201
Specifications
Power/Others
•Power Supply (rated)
14.4 V DC (battery pack), 24.0 V DC (DC IN)
•Power Consumption and Approximate Continuous Recording Times
Values are listed in the following order: Power consumption / Continuous recording time with a BP-A30
battery / Continuous recording time with a BP-A60 battery. The values were measured using normal recording
(second card recording function turned off), with an RF35mm F1.8 MACRO IS STM lens and LCD luminance
set to [Normal].
XF-AVC/MP4
Approx. 14.6 W / 170 min. / 350 min. ([Super 35mm] sensor, 4096x2160 at 59.94P)
Approx. 14.1 W / 175 min. / 360 min. ([Super 35mm] sensor, 4096x2160 at 50.00P)
Approx. 12.4 W / 200 min. / 410 min. ([Super 16mm (Cropped)] sensor, 2048x1080 at 59.94P)
Approx. 12.2 W / 205 min. / 415 min. ([Super 16mm (Cropped)] sensor, 2048x1080 at 50.00P)
• Operating Temperature
0 – 40 °C (32 – 104 °F)
•Dimensions (W x H x D)
6
Camera body only: 160 x 130 x 116 mm (6.3 x 5.1 x 4.6 in.)
Camera with handle unit, microphone holder: 260 x 266 x 171 mm (10.2 x 10.5 x 6.7 in.)
•Weight
6
(including tape measure hook and grip belt)
Camera body: 1,190 g (2.6 lb.)
Camera with BP-A30 battery, 2 cards: 1,420 g (3.1 lb.)
Camera with handle unit, microphone holder, BP-A30 battery, 2 cards: 1,620 g (3.6 lb.)
Accessories
CG-A20 Battery Charger
•Rated Input: 24 V DC, 1.8 A
•Rated Output: 16.7 V DC, 1.5 A
• Operating Temperature: 0 – 40 °C (32 – 104 °F)
•Dimensions
6
(W x H x D): 100 x 24 x 100 mm (3.9 x 0.9 x 3.9 in.)
•Weight
6
: 145 g (5.1 oz.)
CA-CP200 L Compact Power Adapter
•Rated Input: 100 – 240 V AC, 50/60 Hz, 90 VA (100 V AC) – 120 VA (240 V AC)
•Rated Output: 24 V DC, 1.8 A
• Operating Temperature: 0 – 40 °C (32 – 104 °F)
•Dimensions
6
(W x H x D): 67.5 x 37 x 134 mm (2.7 x 1.5 x 5.3 in.)
•Weight
6
: 290 g (10.2 oz.)
