Canon imageCLASS MF267dw - Removing the Reader Motor(SADF Model)

Removing the Reader Motor(SADF Model)
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the SADF Unit + Reader Unit” on page 126
4. “Separating the SADF Unit + Reader Unit” on page 129
5. “Removing the Copyboard Glass (SADF Model)” on page 146
■ Procedure
CAUTION:
• Do not lose the 2 spacers of the Contact Image Sensor Unit.
• Do not touch the document reading part [A] of the Contact Image Sensor Unit.
[A]
1.
4. Parts Replacement and Cleaning
153
