TESTMODE (Service mode for test print, operation check, etc.) > SCAN (SCAN Test Mode)
■ ADJUST
● ADF-ADJ
TESTMODE (Service mode for test print, operation check, etc.) > SCAN (SCAN Test Mode) > ADJUST > ADF-ADJ
DF-SPEED Adj vertical scan magnification: ADF
Detail To adjust vertical scan magnification ratio at ADF stream reading.
As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 %.
+: Image shrinks in the vertical direction
-: Image expands in the vertical direction
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 %
Default Value
0
Supplement/Memo
Same as FEEDER > ADJUST > LA-SPD
DF-OFFSET Adjust the reading start position: ADF
Detail To adjust the reading start position at ADF stream reading.
As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 mm.
+: Leading edge margin becomes smaller. (An image moves to the leading edge.)
-: Leading edge margin becomes larger. (An image moves to the trailing edge.)
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 mm
Default Value
0
Supplement/Memo
Same as FEEDER > ADJUST > DOCST
■ ADFTEST
TESTMODE (Service mode for test print, operation check, etc.) > SCAN (SCAN Test Mode) > ADFTEST
SPEED Specify ADF Motor rotation speed
Detail To specify ADF feeding speed.
Adj/Set/Operate Method
Select the setting value
Display/Adj/Set Range
STDFAX
FINEFAX
SFINEFAX
RGB 300dpi
RGB 150dpi
Gray 300dpi
Gray 150dpi
Mono 300dpi
Mono 150dpi
Related Service Mode
TESTMODE > SCAN > ADFTEST > 2-SIDE
TESTMODE > SCAN > ADFTEST > COUNT
TESTMODE > SCAN > ADFTEST > START
2-SIDE Specify DADF duplex mode
Detail To specify ON/OFF of duplex mode.
Adj/Set/Operate Method
ON and OFF is switched each time OK key is pressed.
Related Service Mode
TESTMODE > SCAN > ADFTEST > SPEED
TESTMODE > SCAN > ADFTEST > COUNT
TESTMODE > SCAN > ADFTEST > START
Supplement/Memo
DADF model only
