Canon imageprograf IPF785 Service Guide

imagePROGRAF iPF785/780 Service Guide
imagePROGRAF iPF785/780 Service Guide August 2014
Page 6
Table 5 – imagePROGRAF iPF785/780 Printer Supplies and Consumables
Supplies and Consumables for imagePROGRAF iPF785/780 Printer
Item
Item Number
1
Ink tank
PFI
－
107MBK
6704B001AA
Ink tank
PFI
－
107BK
6705B001AA
Ink tank
PFI
－
107C
6706B001AA
Ink tank
PFI
－
107M
6707B001AA
Ink tank
PFI
－
107Y
6708B001AA
Ink tank
PFI
－
207MBK
8788B001AA
Ink tank
PFI
－
207BK
8789B001AA
Ink tank
PFI
－
207C
8790B001AA
Ink tank
PFI
－
207M
8791B001AA
Ink tank
PFI
－
207Y
8792B001AA
Maintenance Cartridge MC-10
1320B004BA
Print head PF-04
3630B003AA
1 Item Numbers and Part Numbers are subject to change without notice.
B. Box Contents
Note: Box contents shown are for reference purposes only and are subject to
change without notice.
Table 6 – imagePROGRAF iPF785/780 Printer Box Contents
•
imagePROGRAF
iPF785/780 Printer
• 3INCH adapter BP(u)
• Stand for imagePROGRAF iPF785/780
• (Stand Setup Guide for ST-27/34)
• (Guider for basket)
• Power Cable(USA/Volex)
• PrintHead PF-04 w/o box
• PFI-107 Starter Ink Tanks (1 each of MBK/BK/C/M/Y)
• Setup Guide(E/F/S/P)
• Quick Guide(E/F/S/P)
• Safety Standard/Environment Leaflet
• Carrying Caution Leaflet(JEFIGSCKR)
• Announcement of Large Format Printer Extended Survey Program
• Software CD (Win32/64)
• Software CD for Mac
• PosterAritst Lite CD-ROM
• Paper for adjustment (Coated paper A2x5 –
imagePROGRAF iPF785)
• Call Center Notice
• User Registration Card
• Printer Warranty Card (for CUSA)
• Printer Warranty Card (E/F for Canada)
• Print Head Warranty Card (E/F for USA/CAN)

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
