imagePROGRAF iPF785/780 Service Guide
imagePROGRAF iPF785/780 Service Guide August 2014
Page 14
G. Estimated Installation Times
Estimated installation times shown are the length of time needed to unpack
and install the main unit. The estimated unpacking and installation times are
based on two experienced technicians. Canon USA recommends that service
personnel perform the installation, with four (4) or more persons to unpack
and move the printer, and two (2) or more persons to install it.
Included in the calculation of the estimated installation time are the following:
• Installation space preparation
• Unpacking and positioning the printer (main unit) on a stand or table
• Installing the Printhead, ink tanks, and connecting the power cable
• Checking the printer operation and adjusting the printing position
Table 17 – imagePROGRAF iPF785/780 Printer Estimated Installation Times
Description
Estimated Time
imagePROGRAF iPF785/780 Main Unit (with Stand) 15 minutes
Printhead PF-04 10 minutes
Ink Tanks (time includes installation of all six (6) ink
tanks)
25 minutes
H. Special Tools, Solvents, and Oils List
In addition to the standard tools used to service these devices, the following
special tools should also be carried by a service technician, according to the
tool’s rank. For more information on the special tools, solvents, and oils
below, see the imagePROGRAF iPF785/780 Service Manual.
Table 18 – imagePROGRAF iPF785/780 Printer Special Tools, Solvents and Oils List
Description Rank Part Number
1
Remarks
Cover Switch
Tool
A QY9-0103-000 For enabling the cover switch
Syringe A CK-0541-000
For draining ink manually, and for ink flow
management
Grease PG-
5000H
B FY9-6022-000 Apply to areas specified in the Service Manual
Silbon paper B CK-0336-000 For cleaning
Rubber gloves A QC1-5547-000 For cleaning, and minimizing ink stains on hands
Pen light B CK-0327-000 For visibility when locking and unlocking the carriage
Rank Description
A: Each service person is expected to carry one.
B: Each five or so service persons are expected to carry one.
1 Part numbers are subject to change without notice.

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
