Canon imageprograf IPF785 Service Guide

imagePROGRAF iPF785/780 Service Guide
imagePROGRAF iPF785/780 Service Guide August 2014
Page 2
II. Design Features
A. Direct Print and Share
Direct Print and Share is a Canon cloud-based portal solution that helps users
expand their printing workflow.
• Users can upload documents to their own cloud account using any
WebDAV compliant cloud service.
• Share or print PDFs, TIFFs, JPEGs, and HP-GL/2 files, with the ability to
do batch printing.
• Set up and configure multiple customized “Hot Folders” on the desktop, for
drag and drop printing.
B. imagePROGRAF Print Utility
imagePROGRAF Print Utility is Canon’s mobile app for wireless printing via
an Apple iPad to an imagePROGRAF printer.
• Allows users to review PDF files
• Utilizes basic printer driver settings including number of copies,
orientation, and quality
• Allows the end-user to print to an imagePROGRAF 5-color printer sharing
the same network
• Available for free download through the iTunes App Store
C. Status Monitor
The enhanced imagePROGRAF Status Monitor (Version 25.51) allows for
easy ink replenishment.
• Ink purchase notification function prompts users to reorder ink tanks that
are running low.
• Provides link to website for ink tank purchases
• Provides contact information for a trusted retailer
• Monitored events are user-selectable
D. Accounting Manager
Accounting Manager tracks how much ink and media is being consumed
when printing.
• Allows assignment of ink and paper costs to determine “Cost of goods”
• Allows addition of variable costs to total print job cost
 Ink consumed per Job
 Media consumed per Job
 Job completion time cost
 Other variable costs

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
